LED line EXPERT Modul 1W 95lm 6500K Ultra Tageslichtweiß 170° SMD2835 IP65
- [Wide-angle solution] Ideal for billboards and indoor and outdoor letters
- [Energy-efficient] Luminous efficacy of 95 lm/W with only 1W power consumption
- [Long-lasting] Service life of over 70,000 hours
- [Robust] operates in a temperature range from -40 to 55 °C
- Environmentally friendly: no harmful substances and no mercury
| Quantity | Unit price |
|---|---|
| To 89 | €0.84* |
| To 179 | €0.77* |
| From 180 | €0.74* |
Available, delivery time: 3-5 Werktage
Description
LED line® modules are a wide-angle solution for the illumination of advertising panels and spatial letters.
The colour of light produced by this LED module fall within the range of [[parameterValue_6_Temperatura barwy światła]]. [[parameter_43_Typ diody]] [[parameterValue_43_Typ diody]]. With current consumption of [[parameterValue_14_Prąd]]. [[parameter_13_Wydajność świetlna]] [[parameterValue_13_Wydajność świetlna]]. [[parameter_9_Strumień świetlny]] [[parameterValue_9_Strumień świetlny]]. Our LED modules are powered by constant voltage of [[parameterValue_28_Napięcie zasilania, rodzaj napięcia zasilania]]. [[parameter_33_Kąt świecenia]] [[parameterValue_33_Kąt świecenia]]. [[parameter_86_Klasa szczelności IP65/IP67/IP68]][[parameterValue_86_Klasa szczelności IP65/IP67/IP68]], which ensures strong protection against ingress of water and solid objects.
[[parameter_47_Kompatybilny typ ściemniacza]] [[parameterValue_47_Kompatybilny typ ściemniacza]]. [[parameter_16_Współczynnik odwzorowania barw Ra]] [[parameterValue_16_Współczynnik odwzorowania barw Ra]]. Estimated lifespan of each single diode exceeds [[parameterValue_53_Żywotność]]. [[parameter_19_Klasa Energetyczna]] [[parameterValue_19_Klasa Energetyczna]]. [[parameter_64_Temperatura pracy]] [[parameterValue_64_Temperatura pracy]]. [[parameter_72_Do zastosowań wewnątrz i na zewnątrz pomieszczeń]].
Application:
- spatial coffers
- backlighting purposes
- aquarium backlighting
- outdoor lighting
Technical data
| Beam angle | 170° |
|---|---|
| Color | Beige |
| Color Temperature | 6500 Kelvin |
| Color rendering index | 80 |
| Country of manufacture | Poland |
| Dimmable | No |
| Diode type | SMD2835 |
| EEK spectrum | A-G |
| Energy efficiency class | F |
| IP protection class | IP65 |
| Light color | Ultra daylight white |
| Lighting technology | LED |
| Luminous flux | 95 lumen |
| Material (housing) | PVC |
| Operating temperature | -40/+55 |
| Power | 1 Watt |
| Series | EXPERT |
| Service life L70/B50 | 70000 hours |
| Switching cycles | 50000 |
| Voltage | 12 Volt |
